[FSR101-B35F40] 60KM TX1310/RX1550nm Ethernet Serial Fiber Converter media converter

$999.00

Models Type: 2KM 20KM 60KM TX1310/RX1550nm TX1550/RX1310nmTX1310/RX1550nmTX1550/RX1310nm

Product Overview
Service and Support

FSR101 series is a Multi-serial RS232/RS485/RS422 to Fiber Optic Converter,that transmits serial protocol over fiber optic cable.Fiber Transmission extends serial signal up to 120km.FSR101 series support single-mode,multimode,and single fiber.The serial port interface is terminal block connector for field wiring.FSR101 series automaticllay detects the signal baud rate of the connected serial device,range from 300bps to 115.2Kbps baud. It also automatically adjusts to changes in the conected device

We have the ability to provide a wide range of offerings designed to meet performance and scalability requirements of service providers, enterprise and small and medium business environments, Fibersum devotes to be a Leading Supplier of Networking Solutions!

Wishlist

Technical Specs
Product Overview
Matching Products
Downloads
Reviews

Technical Specs

Part Number(s):FSR101-B35F40
Reach60km
Form FactorStand-alone
Device TypeUnmanaged
EnvironmentOperating temperature 0℃ to 60℃
Maintaining temperature -20℃ to 85℃
Humidity 5%-95% RH
Safety & EmissionCE , FCC, RoHS
PowerInput power 5V to 45 VDC
Working modepoint-to-point
Baud rate300bps to 115.2Kbps
Copper ConnectorTerminal Block
Fiber ConnectorFC as default, ST/SC optional
Transmission distanceRS-232 interface: 15 meters; RS-485/422 interface: 1200 meters
Multi-mode: 2 km; single mode: 20~120 km

Product Overview

Point-Point Transmission
Zero-Delay automatic forwarding
RS232/RS485/RS422 to fiber automatic baud rate detection
Baud rate :300bps to 115.2Kbps
Support multi-mode, single-mode and single-fiber with FC/ST/SC connectors
Support Hot-pluggable
Providing Chassis, Wall-mounted or DIN-Rail installation
supports 1500W surge protection and 15KV ESD protection
External power supply
