- Compatible Part Number(s):1184543P-BX54-120
- Compatible Brand:AdTran
- Vendor P/N(s):SFP100M-BX-54-80
- Transceiver Type:100Base SFP
- Speed:BX
- Wavelength:1550nmTx/1490nmRx
- Distance:100-120KM
- Connector (Interface Type):LC
- Media:SMF
- DDM/DOM:DOM
- TX Power:0~5dBm
- RX Power:<-32dBm
- Optical Components:DFB/PIN
- Product Dimension(H*W*D):1.2 in. x 2.75 in. x 4.75 in.
- Vendor Name:Fibersum
- Operating Temperature:0 to 70℃ (32 to 158℉)
- Protocols:MSA Compliant
BIDI Fast and Gigabit Ethernet SFP is a compact optical transceiver, module used in optical communications for both telecommunication and data bidirectional communications applications.
The IEEE 802.3z standard includes 1000BASE-SX for transmission over multi-mode fiber, 1000BASE-LX for transmission over single-mode fiber, 100BASE-FX is a version of Fast Ethernet over optical fiber. It uses a 1300 nm near-infrared (NIR) light wavelength transmitted via two strands of optical fiber, one for receive(RX) and the other for transmit(TX), 100BASE-SX is a version of Fast Ethernet over optical fiber. It uses two strands of multi-mode optical fiber for receive and transmit. We are produce complete range for FE and GE optical fiber transceivers.
Fiber Bi-Directional SFP Optical TransceiverSimplex SC or LC Connector
1310/1550, 1490/1550, 1310/1490, 1510/1570 or other BOSA TX/RX combination is avalable on request.
AC/AC Coupling according to MSA
RoHS Compliant
0 to 70℃ (32 to 158℉) Temperature - Extended/Industrial Available
Class 1 Laser International Safety Standard IEC 60825 Compliant
